SP-202BSA / SP-203BSA
Vertical Form-Fill-Seal Machine for Powder
Suited for filling food, pharmaceutical chemicals, agricultural chemicals. 35 - 65 angle of repose or particle allowed break, and other non-free flowing powders.
Employs German photocell sensor for accurate control of bag length.
Employs Japanese thermostat for fast heating and superior performance.
The parts through which powders flow are manufactured from stainless steel or Teflon, conform to sanitation standards.
Auger meter filling. Packaging weight is steady.
|Film Width||200 - 360 mm|
|Bag Width||100 - 180 mm|
|Bag Length||150 - 300 mm|
|Packaging Speed||20 - 40 bags/min|
|Volume Range||500 g|
|Power Source||AC 220V 380V|
|Power Consumption||3.35 KW|
|Machine Weight||650 kgs|
|Shipping Weight||850 kgs|
* All specifications are subject to change without prior notice.
